JIS G3460 Low Temperature Pipe

JIS G3460 Low Temperature Pipe

NAME: JIS G3460 Low Temperature Pipe

Delivery Port: Dalian, China

PRICE TERM: EXW, FOB, CFR, CIF, etc.

PAYMENT TERM: T/T, L/C at sight, etc.

Product Details

EO Flanges is specialized in manufacturing and supplying JIS G3460 Low Temperature Pipe for low temperature service. JIS G3460 Low Temperature Pipe is also known as JIS G 3460 Carbon Steel Pipe.

JIS G3460 Low Temperature Pipe's usage: Oil pipe line, oil natural gas, industrial gas, water transportation

Features:

1) Commodity: Seamless and welded austenitic stainless steel pipes

2) Process method: Cold drawn / cold pilgered Thick wall steel pipe| Drill pipe|

3) Surface finish: Annealed / cold pilgered

4) Material: TP304, TP304L, TP310 / S, TP316L, TP316 / 316L dual grade, TP317L, TP321, TP347

5) Standards: ASTM (ASME) SA / A312 / Steel pipe |

6) Size:

A) NPS: 1/8" to 10"

B) Schedule: 5/5S, 10/10S, 20/20S, 40/40S, 80/80S, 120/120S, 160/160S, according to ANSI B36.19/36.10

C) O. D.: 0.405" to 10"

D) W. T.: 0.049" to 1.125"Carbon steel pipe|

7) Length: Max. 13 meters

8) Delivery conditions: Annealed and pickled

9) Applications: For fluid and gas transport; Structural and machining applications Stainless steel pipe




JIS G3460 Low Temperature Pipe Chemical composition table:

CHEMICAL COMPOSITION % max

Steel grade

C

Si

Mn

P

S

Ni

STPL 380

0.25

0.35

1.35

0.035

0.035

　

STPL 450

0.18

0.10-0.35

0.30-0.60

0.03

0.03

3.20-3.80

STPL 690

0.13

0.10-0.35

0.9

0.03

0.03

8.50-9.50



JIS G3460 Low Temperature Pipe Mechanical Property table:


     Steel Grade

Tensile strength

Yield point or proof

Elongation %

stress

kgf/mm2

kgf/mm2

No.11 or No.12 test piece

No.5 test piece

No. 4 test piece

{N/mm2}

{N/mm2}

Longitudinal

Transverse

Longitudinal

Transverse

STPL 380

39 {382}min.

21{206} min.

35 min.

25 min.

30 min.

22 min.

STPL 450

46{451}

25{245} min.

30 min.

20 min.

24 min.

16 min.

STPL 690

70{686}

53{520} min.

21 min.

15 min.

16 min.

10 min.



Production flow of JIS G3460 Low Temperature Pipe

Packaging for JIS G3460 Low Temperature Pipe in bundles wrapped with strong steel strip, seaworthy packing, or according to customers’ requirements.

Delivery of JIS G3460 Low Temperature Pipe is normally 15-30days after receiving T/T deposit


Q: Are you a trading company or a manufacturer?

A: we are factories, and we do trade as well

Question: how long is your delivery time of JIS G3460 Low Temperature Pipes?

A: If JIS G3460 Low Temperature Pipes are in stock, it usually takes 5-10 days. If JIS G3460 Low Temperature Pipes are not in stock, they are for 15-20 days, according to quantity.

Q: Do you provide JIS G3460 Low Temperature Pipes samples? Is it free or extra?

A: Yes, we can supply the JIS G3460 Low Temperature Pipes sample free of charge, but we don't pay the freight.

Q: What are your terms of payment for JIS G3460 Low Temperature Pipes?

A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance, balance before shipment.
