2 PC Automatic Reset Ball Valve

Automatic reset ball valve replaces the torsion spring with the simplest compression spring, and can adjust the torque without changing the spring. Automatically resetting the ball valve All rotary valves with automatic reset handle can realize the function of automatic reset.

Product Details

Products Description

This 2 PC automatic reset ball valve has a simple design and a wonderful appearance. The valve seat has an elastic sealing structure that provides reliable sealing as well as ease of opening and shutting. It is also mounted on the pipeline and is used to open and close the medium in the pipeline. The 2 PC automatic reset ball valve is distinguished by its simple structure and quick switch. The sealing pair's valve core contains a compensating amount. While the valve is worn, spin it a little when it is closed to reliably seal it, extending the valve's service life. If you are interested in it, please do not hesitate to contact us for more information.

Specification
Pressure range: Class 150/Class 300
Face-to-face dimensions: ANSI B16.10-1992
Flange end dimensions: ANSI B16.5
Design: ANSI 16.34, API 608
Test: API 598, API 6D
Material standard: S45C/ASTM A216 GR-WCB/DIN1.00619
SS316/ASTM A351 GR-CF8M/DIN1.4408
SS304/ASTM A351 GR-CF8/DIN1.4308

2 PC Automatic Reset Ball Valve..jpg

Main Parts and Materials

1	Cap	WCB/CF8/CF8M	9	Thrust Washer	PTFE
2	Nut	SS304/SS	10	Packing	PTFE
3	Bolt	SS304/SS	11	Gland	SS304/SS
4	Gasket	PTFE	12	Gland Bolt	SS304/SS
5	Ball	SS304/SS316	13	Handle	SS304/SS
6	Body	WCB/CF8/CF8M	14	Stopper	SS304/SS
7	Seat	PTFE	15	Snap Ring	SS304/SS
8	Stem	SS304/SS316

Main Dimensions

DN	d	B	H	W	C		Do	D1	D	T	f	N-M	L		Do	D1	D	T	f	N-M	L
1/2"	15	11	73	130	42	150LB	35	60.5	89	11	2	4-M15	108	300LB	35	66.5	95	15	2	4-M15	140
3/4"	20	11	76	130	42		43	70	98	11	2	4-M15	117		43	82.5	117	16	2	4-M19	152
1"	25	14	86	160	50		51	79.5	108	12	2	4-M15	127		51	89	124	18	2	4-M19	165
11/4"	32	14	91	160	50		64	89	117	13	2	4-M15	140		64	98.5	133	19	2	4-M19	178
11/2"	38	17	119	200	70		73	98.5	127	15	2	4-M15	165		73	115	156	21	2	4-M19	190
2"	50	17	127	200	70		92	121	152	16	2	4-M19	178		92	127	165	23	2	8-M19	216
21/2"	65	22	136	200	102		105	140	178	18	2	4-M19	190		105	149	190	26	2	8-M22	241
3"	76	22	164	325	102		127	153	190	19	2	4-M19	203		127	169	210	29	2	8-M22	283
4"	94	22	178	325	102		157	191	229	24	2	8-M19	229		157	200	254	32	2	8-M22	305

Packaging & Delivery

Packaging Details of the 2 PC automatic reset ball valve: the strong plywood cases or as per the customer's request.

Delivery Details: 4-5 weeks after receipt of down payment by T/T

Payment: T/T, L/C, Western Union, and PayPal
