Pneumatic Soft Sealed Butterfly Valve

The disc of the EPDM Seat Pneumatic Actuated Butterfly Valve is mounted in the diameter direction of the pipe. In the cylindrical passage of the butterfly valve body, the disc-shaped disc rotates around the axis, and the rotation angle is between 0° and 90°. When the rotation is 90°, the valve is fully open.

Product Details

Quick Details
Standard or Nonstandard:	Standard
Structure:	Butterfly
Pressure:	Medium Pressure
Power:	Solenoid
Material:	Casting
Temperature of Media:	Normal Temperature
Media:	Water
Port Size:	Standard
Place of Origin:	China (Mainland)
Model Number:	OEM
Brand Name:	EO
Application:	Water

SPECIFICATIONS FOR WAFER BUTTERFLY VALVES
Pressure rating and size:	PN10, PN16, Class 125/150
	DN50 to DN1600
	2"~64"
Material:	Body : GGG40, GGG50, GG20, GG25
	Disc : GGG40, GGG50, SS304, SS316
	Stem : 1Cr13, SS304, SS316
	Seal : NBR, EPDM
	Body Seat : F6a, SS304, SS316
Operated type	Worm Gear, Pneumatic, Electric, Bare shaft,etc.
Structure:	Concentric, Double eccentric/offset
Flange connection:	EN1092, ANSI B16.5, GB/T9113
Medium:	Water, sewage
Temperature:	10 to 80°C

Our Service

Spot delivery, including delivering small batches of goods

Provide wide-range and complete materials series products

Cutting plates, including complex shapes of materials and special processing and disposal

Cutting bars and strips

Our application technology expert provide the best material and recommendation

One-stop service
